Leister LHS 410 SF-R (120v/230v/400v) Recirculation Process Heaters
Available in 120V, 230V and 400V options, the new LHS 410 SF-R single flanged recirculation air heaters come with overheat detection with alarm for both the heater and heating element.
Description
Leister LHS 410 SF-R (120v/230v/400v) Industrial Process Single Flange Recirculation Air Heaters
The latest LHS 410 flanged series of advanced industrial process air heaters is distinguished by its flanged design and extremely small dimensions, also now available with more versatility.
The new LHS 410 SF-R (single flange) is considerasbly shorter than the LHS 41 (at 178mm vs 245mm), able to fit into more confined spaces. This 'R' model brings hot air recirculation, and higher energy efficiency, into a wider range of industrial process air heaters. Air inlet temperatures of up to 350ºC are achievable.
Designed for professional integration into machine systems, the new LHS 410 series enables any specific application.
Sterilizing, drying, welding, cleaning, shrinking, shaping, deburring and activating are now more efficient and reliable thanks to Leister’s proven hot-air technology.
Other models in the range include input and output flanges.
Compatible Blowers: Leister ROBUST Industrial Process Blower, Leister MONO System (Built in Airflow Control), Leister AIRPACK Industrial Process Blower
Key Features:
- Small sized heater
- Easy to integrate
- Overheat detection with alarm output for the heating element
- Tool overheat detection with alarm output
- Heating Power: not adjustable
- Power Range: 2 kW to 5.5 kW
- Available in 120V, 230V & 400V
- Air tight up to 1 bar
- Electrical connection separated from airstream
Specification
Leister LHS 410 SF-R Single Flanged Recirculation Industrial Process Air Heater
Technical Details:-
- Power consumption: 2.0 to 5.5 kW
- Heating power: not adjustable
- Detection of heating element and device overheating: Y with alarm output
- Max. air outlet temperature: 650ºC
- Max. air inlet temperature: 350ºC
- Max. ambient temperature: 65ºC
- Max. inlet pressure: 100 kPa
- Weight: 1.6 - 2.0kg
- Min. air flow:
- Compatible Blowers:
- Leister ROBUST Industrial Process Blower
- Leister MONO System (Built in Airflow Control)
- Leister AIRPACK Industrial Process Blower
LHS410 Installation Dimensions:
